A mechanical slip packer set by first lifting and then setting down the tubing. Movement of the guide pin expands the slips and compresses the element; lifting the string releases the assembly.
| Model | Tool OD (mm) | Tool ID (mm) | Working differential (MPa) | Setting load (kN) | Temperature rating (°C) |
|---|---|---|---|---|---|
| Y211-90 | 90 | 32 | 25 | 60-80 | 120 |
| Y211-115 | 115 | 52 | 35 | 80-120 | 120 |
| Y211-148 | 148 | 70 | 35 | 80-120 | 120 |
The sealing element is made from nitrile rubber; the friction-block spring is a high-strength die spring.
Used for zonal testing, production, water detection, water shutoff and large-pump production.
YUXIN combines product engineering, machining, assembly, inspection and export coordination in Dongying, Shandong.
Send the existing model or drawing, connection dimensions, operating pressure and temperature, well conditions, quantity and destination.
Yes. YUXIN can review drawings and samples for material, tolerance, machining, inspection and batch-production feasibility.
Material and treatment options are selected around pressure, load, corrosion, wear, temperature and sour-service requirements.
Inspection planning can include dimensional checks, material documentation, assembly review and product-specific pressure or functional testing.
Yes. Batch supply, export packing and order documentation can be organized for distributors, service companies and project procurement.
Website data is for preliminary selection. Final compatibility is confirmed against the approved drawing, specification and purchase requirements.
