APPLICATION-SPECIFIC CONFIGURATION
Cyclonic Downhole Desander
Overview
A downhole desander that creates high angular velocity through a tangential inlet. Density separation drives solids into an outer downward spiral toward the tailpipe while the cleaner liquid moves upward through the inner vortex.
Direct ManufacturerDrawing-Based SupplyExport Support
Product Advantages
- Non-plugging separation structure
- Separates fine sand and silt below 0.05 mm as stated in the source
- All-metal pressure-bearing construction
- Compact reusable assembly
- Secondary settling section for lighter impurities
Technical Specifications
| 模型 | 总长度（毫米） | 最大外径（毫米） | 最小内径（毫米） | 分离粒径（毫米） | 抗拉强度（kN） | 流体处理能力（立方米/天） | 适用井下介质粘度（MPa·s） | 适用的套管内径（毫米） | 适用井砂含量（‰） |
|---|---|---|---|---|---|---|---|---|---|
| XLCS-108 | 2100±10 | 108 | 38 | >0.05 | ≥350 | ≤980 | <30 | >121.1 | <1.5 |
| XLCS-90 | 1380 ± 10 | 90 | 30 | <0.05 | ≤350 | ≤352 | <30 | >121.1 | <1.5 |
| XLCS-80 | 1280 ± 10 | 80 | 25 | <0.05 | ≤350 | ≤198 | <30 | >90 | <1.5 |
Operating Applications
Manufacturing Support
Built for Controlled Oilfield Supply
YUXIN combines product engineering, machining, assembly, inspection and export coordination in Dongying, Shandong.
20+Years of industry experience
5,000+ m²Manufacturing base
40+Equipment sets
30+Core product series
Product FAQ
Before You Request a Quote
What information is needed to confirm the correct configuration?
Send the existing model or drawing, connection dimensions, operating pressure and temperature, well conditions, quantity and destination.
Can this product be manufactured from a drawing or sample?
Yes. YUXIN can review drawings and samples for material, tolerance, machining, inspection and batch-production feasibility.
Which materials and surface treatments are available?
Material and treatment options are selected around pressure, load, corrosion, wear, temperature and sour-service requirements.
How is the product inspected before shipment?
Inspection planning can include dimensional checks, material documentation, assembly review and product-specific pressure or functional testing.
Can YUXIN support distributor and project orders?
Yes. Batch supply, export packing and order documentation can be organized for distributors, service companies and project procurement.
How is final compatibility confirmed?
Website data is for preliminary selection. Final compatibility is confirmed against the approved drawing, specification and purchase requirements.
